Hobby servos pack motor, gearbox and feedback into a box you command by pulse width. 1 ms ≈ 0°, 1.5 ms ≈ 90°, 2 ms ≈ 180°, repeated every 20 ms. The Servo library generates this stream; your job is wiring the power properly.
At a glance: 7 minute guide · part 9 of 10 in the complete Arduino guide track · includes a worked example and a quick-reference table.
The protocol
Here is the working theory in one pass. The servo library attaches to any digital pin and outputs the 50 Hz pulse train. write() takes degrees; writeMicroseconds() gives finer control. Standard servos sweep ~180°, continuous-rotation versions map the pulse to speed and direction instead.
| P | u | l | s | e | w | i | d | t | h | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| T | y | p | i | c | a | l | a | n | g | l | e | |
| N | o | t | e | |||||||||
| 1000 µs | 0° | Minimum check datasheet | ||||||||||
| 1500 µs | 90° | Centre, safe default | ||||||||||
| 2000 µs | 180° | Maximum check datasheet | ||||||||||
| 20 ms period | 50 Hz refresh, library-managed |
Power: the real problem
A stalled servo can draw an amp the Arduino 5 V rail collapses, brownouts follow, and USB ports protest. Power servos from a separate 5-6 V supply with common ground to the Arduino. A 470 µF electrolytic across the servo rail absorbs the surges.
Smooth and safe motion
Sweeping instantly between angles slams the gearbox. Ramp the angle a degree at a time for mechanical kindness. Under no load a servo hums while holding position that is normal current draw, another reason not to feed it from the logic rail.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Power the servo from its own 5-6 V supply
- Tie supply ground and Arduino ground together
- Attach the servo pin and centre it before mechanical fixing
- Ramp angles in code for gentle motion
Worked example
A pan platform driven from the 5 V pin jittered and reset the board whenever it hit end-stops. Moving it to a 6 V, 2 A supply with common ground eliminated every reset. Run the numbers yourself with the related calculator and the result should agree to within rounding.
Practical note from the bench. Procirel robotics rule: every servo rail gets a bulk capacitor at the connector, and every supply budget sums stall currents, not running currents.
Pitfalls that cost real hardware
- Powering servos from the Arduino 5 V pin
- Forgetting the common ground between supplies
- Assuming 0-180° maps to exactly 1-2 ms on every brand
Key takeaways
- The protocol the foundation of this guide; revisit it if any measurement here surprises you.
- Power: the real problem the foundation of this guide; revisit it if any measurement here surprises you.
- Smooth and safe motion the foundation of this guide; revisit it if any measurement here surprises you.
