analogWrite() does not output analog voltage. It outputs a square wave at ~490 Hz whose duty cycle the share of time high sets the average energy. Motors see speed, LEDs see brightness, and filters see a controllable DC level.
At a glance: 7 minute guide · part 3 of 10 in the complete Arduino guide track · includes a worked example and a quick-reference table.
Duty cycle math
Here is the working theory in one pass. A value of 0-255 maps to 0-100 % duty. analogWrite(pin, 128) yields ~50 % duty, so a 5 V-driven LED averages about 2.5 V and a motor runs at roughly half speed. Average voltage = supply × duty.
| a | n | a | l | o | g | W | r | i | t | e | v | a | l | u | e | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | u | t | y | c | y | c | l | e | |||||||||||||
| A | v | e | r | a | g | e | v | o | l | t | a | g | e | a | t | 5 | V | ||||
| 0 | 0 % | 0 V | |||||||||||||||||||
| 64 | 25 % | 1.25 V | |||||||||||||||||||
| 128 | 50 % | 2.5 V | |||||||||||||||||||
| 192 | 75 % | 3.75 V | |||||||||||||||||||
| 255 | 100 % | 5 V (constant high) |
What PWM can and cannot do
It works beautifully for anything with inertia or persistence. Motors, heaters, LED brightness, servo signalling (servos use their own 50 Hz protocol via the library). It cannot directly power an analog input of another board low-pass filter it first (a resistor and capacitor roll off the ripple).
Frequency and noise
Pins 5 and 6 run at ~980 Hz on an Uno; the others at ~490 Hz. Audible whine in a motor or flicker in a camera frame are frequency artifacts. Timer libraries can shift PWM frequency when the default annoys ears or sensors.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Pick a PWM-capable pin (3,5,6,9,10,11 on Uno)
- Call analogWrite(pin, 0-255)
- For true analog voltage, add an RC low-pass filter
- Check the load tolerates ~490 Hz switching
Worked example
Dimming an LED: analogWrite(9, 51) ≈ 20 % duty ≈ 1 V average. The eye integrates the pulses into steady dimness no filter needed. Run the numbers yourself with the LED Resistor Calculator and the result should agree to within rounding.
Practical note from the bench. Procirel tip: a 220 Ω resistor plus 10 µF capacitor turns any PWM pin into a usable 0-5 V analog source for testing op-amp circuits.
Pitfalls that cost real hardware
- Expecting analogWrite to drive an analog input directly without filtering
- Using PWM pins 0/1 (they are not PWM plan around serial)
- Overlooking audible whine from 490 Hz in gearmotors
