Before debuggers, before logic analysers, there is Serial. The UART channel between board and computer prints values, streams sensor readings. Receives commands the single most-used tool in embedded development.
At a glance: 6 minute guide · part 4 of 10 in the complete Arduino guide track · includes a worked example and a quick-reference table.
How UART works
Serial sends bytes as start bit, 8 data bits, stop bit at an agreed baud rate 9600 and 115200 are the everyday choices. Both ends must agree; a mismatch turns text into mojibake. On the Uno, hardware serial shares pins 0/1 with the USB chip. Is why uploads fail while Serial Monitor holds the port.
| B | a | u | d | r | a | t | e | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| B | y | t | e | s | / | s | e | c | ( | a | p | p | r | o | x | ) | |
| T | y | p | i | c | a | l | u | s | e | ||||||||
| 9600 | ~960 | Default examples, GPS | |||||||||||||||
| 57600 | ~5,760 | Displays, modems | |||||||||||||||
| 115200 | ~11,520 | Fast logging, ESP boot messages | |||||||||||||||
| 1,000,000+ | ~100,000 | Debug floods on faster boards |
Printing for humans and machines
Serial. print() and println() output text; Serial. write() sends raw bytes. For readable logs, label everything and delimit fields with commas or tabs later you can paste the stream straight into a spreadsheet. For machine links, binary framing with start bytes and checksums beats text parsing.
Beyond the USB cable
The same UART protocol links Arduino to GPS modules, Bluetooth adapters and ESP32 boards just cross-connect TX→RX both ways at matching voltage levels. SoftwareSerial can add ports, but hardware serial is more reliable at speed.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Start serial at a chosen baud in setup()
- Match the Serial Monitor baud selector exactly
- Label every printed value for readable logs
- Close the monitor before uploading on boards that share the port
Worked example
Logging a thermistor: Serial. print("T="); Serial. print(t, 1); Serial. println(" C"); produces "T=24.7 C" lines instantly plottable and greppable. Run the numbers yourself with the related calculator and the result should agree to within rounding.
Practical note from the bench. Habit worth stealing: prefix every debug line with millis() timestamps convert vague "sometimes" bugs into measurable events.
Common mistakes to avoid
- Mismatched baud rates producing garbage characters
- Printing floats without a digit limit kilobyte logs
- Trying to use pins 0/1 for both serial devices and USB debug
Key takeaways
- How UART works the foundation of this guide; revisit it if any measurement here surprises you.
- Printing for humans and machines the foundation of this guide; revisit it if any measurement here surprises you.
- Beyond the USB cable the foundation of this guide; revisit it if any measurement here surprises you.
Prerequisites and preparation
Before starting. Start serial at a chosen baud in setup() and match the serial monitor baud selector exactly. Keep a calculator to hand every number in the worked example is reproducible. Total time including the bench steps: about 6-6 minutes.
Who benefits most
Hobbyists meeting this topic for the first time, students who want the version with real numbers instead of abstract symbols. Returning engineers refreshing a corner of the craft. The mistake list alone justifies the visit every entry in it was learned the expensive way.
Quick reference card
| Aspect | Where to find it in this guide |
|---|---|
| Core theory | How UART works |
| Application steps | How to apply this in your build |
| Worked numbers | Worked example |
| Failure modes | Common mistakes to avoid |
How this fits the complete Arduino guide track
This guide is one stop in the structured learning path. Start from the complete Arduino guide complete guide for the full map, or continue with I2C versus SPI communication and Arduino IDE setup.
Frequently asked questions
Why does my board print symbols after reset? Bootloaders and boot messages run at different bauds the first lines are normal noise on some chips.
What is the fastest safe baud on an Uno? 115200 is dependable; beyond that the 16 MHz chip struggles to also run your sketch.
Where do I go next? Back to the complete Arduino guide complete guide it indexes every guide in this track and updates as new ones are published.
