The heavy linear supply with its 50 Hz transformer and the featherweight SMPS switching at 65 kHz+ solve the same problem with opposite philosophies. Understanding both explains every wall wart you will ever open.
At a glance: 7 minute guide · part 5 of 10 in the power supplies and batteries complete guide track · includes a worked example and a quick-reference table.
Linear supplies
Here is the working theory in one pass. Transformer → rectifier → reservoir → linear regulator. Excellent ripple rejection, no high-frequency noise, tolerant of abuse. Physics charges for it: a 50 Hz transformer scales in iron and copper. Efficiency sags badly below full load.
| Aspect | Linear | SMPS |
|---|---|---|
| Weight/power | Poor (iron) | Excellent |
| Efficiency at load | 30-60 % | 85-94 % |
| Low-load efficiency | Poor | Good with modern parts |
| Output noise | µV ripple | mV switching residue |
| EMI concerns | Minimal | Filtering mandatory |
| Isolation | Inherent | Designed in |
Switching supplies
What this means at the bench. Rectify mains directly, chop at high frequency through a small ferrite transformer, rectify and regulate. Ten times the power density, universal input ranges, 85 %+ efficiency across load. The price: conducted and radiated EMI that must be filtered, and transient behaviour to respect.
Choosing in practice
Audio measurement gear and precision analog: linear or hybrid. Everything portable or embedded: switchers. Bench instruments often combine a switcher front-end pre-regulating into a linear last stage for quiet outputs at reasonable efficiency.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- List noise sensitivity of every load on the rail
- Compare total dissipation at realistic load
- Plan filtering and layout early for switchers
- Consider hybrid when both efficiency and quiet matter
Worked example
A lab 30 V/3 A linear bench supply weighs 8 kg and idles warmly. The equivalent SMPS brick weighs 400 g. For logic boards the SMPS wins outright. For a µV-level preamp, the linear stage is not optional. Run the numbers yourself with the LM317 Regulator and the result should agree to within rounding.
Practical note from the bench. Our supply reviews always measure ripple in mV/mm at two loads the scope photo settles the linear-versus-switching argument faster than adjectives.
Field mistakes we see again and again
- Putting a noisy SMPS next to a precision analog front end and blaming the parts
- Assuming SMPS isolation without checking the safety certification
- Underrating linear supplies for heat inside sealed enclosures
Key takeaways
- Linear supplies the foundation of this guide; revisit it if any measurement here surprises you.
- Switching supplies the foundation of this guide; revisit it if any measurement here surprises you.
- Choosing in practice the foundation of this guide; revisit it if any measurement here surprises you.
Who this guide is for
Beginners get a single focused topic instead of a whole textbook chapter. It assumes the track’s earlier pages in the power supplies and batteries complete guide path. Intermediate readers use it as a reference the table, the worked example and the mistake list answer the questions that come up mid-build. If you teach, the structure (theory, application, example, failure modes) maps cleanly onto a lab session.
What you need before starting
Nothing exotic: the parts or tools named in the guide, a multimeter. The LM317 Regulator open in a tab. List noise sensitivity of every load on the rail before you begin the guide assumes it and keep the quick-reference table above within sight while you work through the steps.
Quick reference card
| Aspect | Where to find it in this guide |
|---|---|
| Core theory | Linear supplies |
| Application steps | How to apply this in your build |
| Worked numbers | Worked example |
| Failure modes | Field mistakes we see again and again |
How this fits the power supplies and batteries complete guide track
This guide is one stop in the structured learning path. Start from the power supplies and batteries complete guide complete guide for the full map, or continue with regulator topologies and reservoir sizing. For the arithmetic, open the LM317 Regulator.
Frequently asked questions
Are SMPS unsafe for audio? No with proper layout and post-filtering they vanish into the noise floor; countless professional amps run switchers.
Why do bench supplies stay linear? Ultra-low noise, precise transient behaviour and durability under abuse the lab pays in weight for those virtues.
Is there a calculator for this? Yes the LM317 Regulator tool runs the formulas from this guide instantly, client-side, with no signup.
Related guides and tools
- The complete power & batteries guide: Power & Batteries complete guide
- Read next: bms design tutorial: battery management systems explained
- Also in this track: solar mppt explained: maximum power point tracking
- Continue with: linear vs switching regulators: choosing correctly
- Calculate as you go: runtime estimator · regulator designer · capacitor code tool
- From here, the natural continuation is the next guide in the track index. It assumes exactly the vocabulary this page built and adds the next layer of practice.
Verification routine
Component substitution is a legitimate experiment as long as it is deliberate. Swap one part, predict the effect, measure, and record. That single habit converts a parts bin into a teaching lab and makes every future guide in this track faster to absorb.
The fastest way to internalise this topic is to change one variable deliberately and predict the result before measuring. Wrong predictions are the curriculum, they show exactly which mental model needs revisiting, and the bench grades honestly.
Formulas and checks from this guide
Verification checklist for this track. Verify regulation under load, not just open-circuit, measure inrush where it matters. Treat every lithium cell as energetic chemistry that has earned its protection chain.
Bookmark this page against your next build in the track. The checklist above is the same one used across 18 guides in this series.
Notes from the bench
Any lithium pack of 2S or more, without exception.
No. Oversizing hammers the diodes with inrush and buys ripple you no longer need once regulation follows.
Extended Application Notes
This section expands the practical application of smps vs linear power supplies: an honest comparison beyond the worked example, into the situations builders actually meet. Component substitution: when the exact specified part is unavailable, the substitution logic follows the governing parameter of this design, not the nominal value, and the verification step after any substitution is to re-measure the one quantity this guide identified as critical. Batch variation: components vary, and the design margins recommended in the sections above absorb that variation; if a second build behaves differently, the difference itself is diagnostic and points to the tolerance that dominated. Environmental limits: temperature, supply variation and ageing each push a real circuit away from its bench behaviour, and the recommended practice is to test the extremes deliberately rather than discover them in the field. These notes exist because the bench taught them, repeatedly, and each one was once a real troubleshooting session that ended in understanding.
Failure Analysis in Depth
The mistakes section above lists the traps; this section explains why each trap exists and how to recognize it early. Putting a noisy SMPS next to a precision analog front end and blaming the parts Assuming SMPS isolation without checking the safety certification Underrating linear supplies for heat inside sealed enclosures. Each of these failures has a signature that appears in measurement before it appears in smoke: a reading that drifts, a waveform that differs from the prediction, a temperature that climbs faster than the calculation. The discipline this guide teaches is to measure at the first sign, not at the last, and the sections above give the specific instrument and setting for each check. Failure analysis is not pessimism; it is the fastest curriculum in electronics, because a fault understood once is a fault prevented forever.
Pre-Build Checklist
Before powering any build of this design, run the list: every component value verified against the specification above, the critical measurement points identified and accessible, the instrument modes and ranges chosen in advance, the expected values written down beside the bench, and the power source current-limited for first application. The checklist takes two minutes and replaces the most expensive class of beginner error, which is not ignorance but confidence outrunning verification. Builders who adopt the checklist across the guides in this track report first-apply success rates that feel like cheating, but it is not cheating, it is engineering.
What Comes Next
Having worked through this guide, the natural next steps are the adjacent guides in the track index above, each of which assumes exactly the vocabulary this page built. The calculators linked in the tools section verify every number in seconds, and the complete guide at the head of this track maps the entire curriculum. Read once, build once, measure always: that is the method this site teaches and the method every section above followed before publication.
Theory in Practice, Extended
The theory section of smps vs linear power supplies: an honest comparison deserves one more pass with the bench in mind, because knowing a relationship and applying it under constraint are different skills. In application, the relationship is never isolated: it interacts with tolerances, with temperature, with the behaviour of adjacent stages, and with the measurement itself. The extended practice is to take the governing formula from the sections above and stress it, deliberately. Push the input to the edge of its specified range and watch the output follow the prediction, then push past it and watch the prediction break, because the edge of the specification is exactly where the formula stops being the whole story. That boundary, found on the bench rather than in the datasheet, is the real knowledge this guide offers beyond the mathematics.
Component Sourcing and Substitution Notes
Real builds meet real supply chains, and this section addresses the practical reality. The specified components in this guide were chosen for the reasons stated in the design sections, but equivalent parts from reputable manufacturers almost always serve, provided the governing parameters match, not merely the nominal ones. The substitution checklist: match the parameter this guide identified as critical, verify the package and pinout against the physical part before layout, check the datasheet revision for silent changes, and re-run the verification measurement after installation. Avoid unbranded surplus and marketplace components for anything this guide treats as safety-relevant; the failure mode of a counterfeit is not degradation, it is unpredictability, and unpredictability defeats every other design decision in the chain.
Instrumentation for This Design
Every measurement recommended in this guide maps to a specific instrument configuration, and this section consolidates them. Voltage checks: DC range selected before probing, leads verified against a known source, meter burden considered when the node is high impedance. Current checks: circuit broken at the defined point, meter inserted with the correct range and fuse status confirmed first. Waveform checks: probe compensated against the reference before any amplitude claim, ground lead kept short, bandwidth sufficient for the edge rather than the repetition rate. The instrumentation discipline matters more than the instrument class, and a modest instrument used correctly outperforms an expensive one used casually, a claim this site demonstrates throughout its measurement guides.
Documentation Template for This Build
Close the loop the way professional builds do: record the design values from this guide, the as-built values including every substitution, the measured results beside the predicted ones, and the deviation notes that explain every gap. The template is short, a single page, and it converts a successful build into a reference that survives component changes, firmware updates and the passage of months. Every guide on this site was built and documented exactly this way before publication, and the discipline is offered here as part of the curriculum rather than an afterthought. A build that is documented is twice built, once in copper and once in confidence.
The Decision Table in Practice
Linear or switching comes down to what you cannot tolerate. Cannot tolerate noise (phono preamps, RF receiver front ends, precision ADC references): linear or LDO post-regulated, full stop; a 60dB-quiet linear supply is ordinary, and no cheap switcher gets close. Cannot tolerate heat or weight (any supply over ~30W, battery chargers, LED drivers, anything portable): switching; a 100W linear supply is a 2kg transformer and a heatsink you could fry an egg on, while a 100W switcher fits in your palm and runs warm. Cannot tolerate cost (high-volume products, BOM-sensitive designs): switching, whose magnetics and controller cost less than a suitably rated transformer at almost every power level above a few watts. The professional default for mixed systems is hybrid: a switcher does the heavy lifting (mains to 12V, or 48V to 5V), then linear/LDO stages clean the rails that matter. The hobbyist default for bench power remains linear, because a bench supply's job is to be transparent, and transparency is the one thing switching supplies have to work hardest to fake.
