Knowing how boards are made changes how you design them. Every DRC rule traces to a machine limit; every finish choice traces to a process step. A weekend understanding of fab work makes you a better designer immediately.
At a glance: 7 minute guide · part 9 of 10 in the PCB design complete guide track · includes a worked example and a quick-reference table.
The core processes
Here is the working theory in one pass. Two-layer boards start as fully copper-clad laminate. Photoresist and UV exposure protect the wanted copper; etching removes the rest. Drilling precedes plating via walls are metallised so holes conduct between layers. Multilayer boards laminate etched cores with prepreg.
| Step | What happens | Design impact |
|---|---|---|
| Drill | CNC holes | Min drill, annular ring |
| Plating | Via metallisation | Current per via |
| Etch | Copper removal | Min width/spacing |
| Lamination | Layers bond (ML) | Stack-up planning |
| Mask + silk | Green coat + legend | Pad openings, silk rules |
| Finish | HASL/ENIG/OSP | Flatness, shelf life |
Masks, silk and finishes
Liquid solder mask is applied, exposed and developed those green openings are precisely your pad geometry. Silkscreen prints legends. Surface finish (HASL, ENIG, OSP) protects copper and determines solderability shelf life; ENIG is flat and gold, ideal for fine pitch.
Choices you actually control
Copper weight, board thickness, finish, solder-mask colour, and electrical test. Fab electrical test (flying probe) verifies continuity against your netlist worth the trivial cost on every order. Panelisation options matter only when assembly automation enters.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Check the fab capability list before finalising rules
- Choose finish by pitch and shelf-life needs
- Order electrical test on every batch
- Keep one spare set of Gerbers archived per revision
Worked example
A 0.35 mm BGA design sent with default HASL failed assembly the uneven finish pooled under pads. The same board in ENIG assembled on the first attempt. Run the numbers yourself with the related calculator and the result should agree to within rounding.
