MQTT is a tiny publish/subscribe protocol: devices publish messages to named topics. Anyone subscribed to those topics receives them. Neither side needs to know the other exists which is exactly why it scales from one sensor to factory floors.
At a glance: 8 minute guide · part 4 of 10 in the complete IoT and ESP32 guide track · includes a worked example and a quick-reference table.
Topics and the broker
A broker (Mosquitto, HiveQ…) routes everything. Topics are hierarchical strings home/livingroom/temperature and subscriptions accept wildcards: home/+/temperature or home/#. One broker, hundreds of quiet clients.
| C | o | n | c | e | p | t | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| W | h | a | t | i | t | d | o | e | s | ||
| T | y | p | i | c | a | l | u | s | e | ||
| Topic | Named channel | home/kitchen/temp | |||||||||
| + / # wildcards | Subscribe patterns | + filters one level | |||||||||
| QoS 1 | At-least-once delivery | Most telemetry | |||||||||
| Retained | Last value kept for new subscribers | Switch/desired state | |||||||||
| LWT | Announces unexpected death | Device offline alerts |
QoS levels and retained messages
QoS 0 sends and forgets; QoS 1 guarantees at-least-once (duplicates possible). QoS 2 guarantees exactly-once with more overhead. Retained messages let a new subscriber instantly learn the last known value perfect for state topics like switch positions.
Keepalive, LWT and security
Keepalive pings detect silently dead clients; the Last Will message publishes on ungraceful drops. Use username/password at minimum, TLS where feasible. Never expose a broker to the raw internet VPN or an authenticated bridge is the sane pattern.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Design a topic tree before wiring any devices
- Publish telemetry to state topics, subscribe to command topics
- Enable retained messages for state, not for streams
- Set keepalive and a Last Will for every device
Worked example
A thermostat publishes home/bedroom/setpoint (retained) and home/bedroom/temperature (QoS 0, every 30 s). Home Assistant restarts and instantly knows the setpoint without asking. Run the numbers yourself with the related calculator and the result should agree to within rounding.
Practical note from the bench. Topic naming pays compound interest: location/device/measurement reads itself. We document the tree in the project README before flashing anything.
Common mistakes to avoid
- Publishing high-rate streams as retained brokers bloat
- Chatty QoS 2 on battery devices handshakes cost milliamp-hours
- Open broker port forwarded to the internet "temporarily"
Key takeaways
- Topics and the broker the foundation of this guide; revisit it if any measurement here surprises you.
- QoS levels and retained messages the foundation of this guide; revisit it if any measurement here surprises you.
- Keepalive, LWT and security the foundation of this guide; revisit it if any measurement here surprises you.
