5G is not just “4G but faster”, it is a radio and core network redesigned around three different promises. Enhanced mobile broadband, massive IoT, and ultra-reliable low latency. Understanding which of the three a use case needs explains every technology choice inside it.
At a glance: 9 minute guide · part of the IoT and ESP32 complete guide track · worked example, quick-reference table and field notes included.
The three service classes
eMBB delivers multi-gigabit broadband to people. mMTC (massive machine-type communication) connects millions of low-power devices per square kilometre. URLLC targets millisecond latency with five-nines reliability for industry and vehicles. No single radio serves all three, 5G is a family of profiles.
The radio side: massive MIMO and mmWave
Base stations deploy dozens of antennas, beamforming signals precisely to each user, capacity multiplies without new spectrum. Millimetre-wave bands add enormous bandwidth at short range, demanding dense small cells. Sub-6 GHz carries the coverage burden.
The core: virtualised and sliced
The 5G core is software running on standard compute, with network functions virtualised. Its signature feature is slicing: logically isolated networks on shared infrastructure, one slice tuned for IoT telemetry, another for latency-critical control, each with its own guarantees.
| Complete Guide | Target | Enabling tech |
|---|---|---|
| eMBB | Multi-Gbps broadband | mmWave, massive MIMO |
| mMTC | Millions of devices/km² | NB-IoT class protocols |
| URLLC | ~1 ms, 99.999 % | Edge cores, grant-free access |
| Slicing | Isolated virtual nets | Virtualised 5G core |
