The DHT22 reports temperature and humidity over a quirky single-wire protocol every two seconds. It is cheap, cheerful and everywhere and it works flawlessly on ESP32 once you respect its timing and pull-up requirements.
At a glance: 6 minute guide · part 6 of 10 in the complete IoT and ESP32 guide track · includes a worked example and a quick-reference table.
Wiring and pull-ups
VCC to 3.3 V, GND to GND, DATA to a chosen GPIO with a 10 kΩ pull-up to 3.3 V (many breakout modules carry one). Long cable runs degrade the single-wire timing keep it short or move to I²C sensors like the BME280 for distance.
| P | r | o | p | e | r | t | y | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | H | T | 2 | 2 | |||||||||||
| B | M | E | 2 | 8 | 0 | ( | u | p | g | r | a | d | e | ) | |
| Interface | 1-wire timing | I²C | |||||||||||||
| Minimum read interval | 2 s | Continuous | |||||||||||||
| Accuracy | ±0.5 °C / ±2-5 %RH | ±0.5 °C / ±3 %RH | |||||||||||||
| Extra outputs | Pressure | Cost | Low | Moderate |
Reading rules
The sensor needs ≥2 s between reads; faster polling returns cached or NaN values. The Adafruit library handles the protocol; read with a null check and retry logic, because one missed bit checksums the whole packet out.
Accuracy expectations and checks
±0.5 °C and ±2-5 %RH are realistic, with humidity drifting over years of service. Sanity-check two sensors side by side; a 2 °C permanent offset deserves calibration constants, not guesswork. For serious logging, step up to SHT31 or BME280.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Wire with the 10 kΩ pull-up on the data line
- Wait two seconds between reads
- Check for NaN returns and retry once
- Validate two sensors side by side before trusting either
Worked example
A greenhouse monitor polled every 500 ms and logged NaNs hourly. Moving to a 2.5 s cadence with a single retry produced a month of gap-free data from the same hardware. Run the numbers yourself with the related calculator and the result should agree to within rounding.
Practical note from the bench. Every climate build we publish states sensor accuracy honestly ±0.5 °C is plenty for comfort control, marginal for scientific logging.
Pitfalls that cost real hardware
- Polling faster than the 2 s protocol allows
- Leaving the pull-up off on a bare sensor
- Trusting absolute humidity values that were never calibrated
Key takeaways
- Wiring and pull-ups the foundation of this guide; revisit it if any measurement here surprises you.
- Reading rules the foundation of this guide; revisit it if any measurement here surprises you.
- Accuracy expectations and checks the foundation of this guide; revisit it if any measurement here surprises you.
Prerequisites and preparation
Before starting: wire with the 10 kω pull-up on the data line and wait two seconds between reads. Keep a calculator to hand every number in the worked example is reproducible. Total time including the bench steps: about 6-6 minutes.
Who benefits most
Hobbyists meeting this topic for the first time, students who want the version with real numbers instead of abstract symbols, and returning engineers refreshing a corner of the craft. The mistake list alone justifies the visit every entry in it was learned the expensive way.
Quick reference card
| Aspect | Where to find it in this guide |
|---|---|
| Core theory | Wiring and pull-ups |
| Application steps | How to apply this in your build |
| Worked numbers | Worked example |
| Failure modes | Pitfalls that cost real hardware |
How this fits the complete IoT and ESP32 guide track
This guide is one stop in the structured learning path. Start from the complete IoT and ESP32 guide complete guide for the full map, or continue with ultrasonic distance sensing and ESP32 starter guide.
Frequently asked questions
DHT11 or DHT22? DHT22 costs a little more for half the temperature error and better humidity range worth it for anything you log.
Why do I get NaN occasionally? A checksum failure read too soon, marginal wiring, or missing pull-up. Retry logic is standard practice.
Where do I go next? Back to the complete IoT and ESP32 guide complete guide it indexes every guide in this track and updates as new ones are published.
