Decoupling Capacitor Placement: The Physics of "Put It Closer"

Decoupling capacitors are local energy reservoirs. Their entire value is loop area. A perfect capacitor a centimetre away performs worse than an adequate one at the pin. Placement is not finishing touch it is the design.

At a glance: 7 minute guide · part 7 of 10 in the PCB design complete guide track · includes a worked example and a quick-reference table.

The local reservoir job

Here is the working theory in one pass. When an IC switches, it draws current in nanosecond bursts. The regulator cannot respond that fast and trace inductance strangles delivery. The local cap supplies the transient, then recharges slowly. Larger bulk caps (10 µF class) refuel the small ones.

Capacitor	Value	Serves	Placement
Ceramic	100 nF	Switching transients	At the pin, ≤ 5 mm
Ceramic/bulk	1-10 µF	Slower local sag	Per IC section
Electrolytic	47 µF+	Board-level reserve	Power entry
Tantalum/poly	10-100 µF	Bulk on compact boards	Regulator output

Value stacks and why

A classic 100 nF + 10 µF pair covers two frequency decades. Ceramic for fast edges, bulk for slower sag. Antiresonance between values exists but is secondary to placement a correctly placed pair beats an exotic single part any day.

Placement geometry

Capacitor to power pin, capacitor to ground via: both paths short and wide. Vias beside (not in) pads when hand-soldering, in pads when the fab fills them. One cap per power pin for fast ICs. Sharing caps between neighbouring ICs reintroduces exactly the coupling decoupling prevents.

How to apply this in your build

Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.

1. Place the fastest capacitor closest to each power pin
2. Drop the ground via immediately beside the capacitor
3. Add bulk capacitance at the regulator and board entry
4. Audit layout: every IC power pin within 5 mm of its cap

Worked example

A microcontroller resetting during WiFi transmit had its 100 nF "conveniently" grouped 20 mm away. Moving the caps to the pin pair eliminated the brownout entirely same BOM, different geometry. Run the numbers yourself with the Capacitor Code (3-Digit) and the result should agree to within rounding.

Practical note from the bench. Layout reviews on Procirel boards always zoom to each IC power pin if the cap is not visibly attached, the review stops there.

Common mistakes to avoid

• Grouping all decoupling at the board edge "neatly"
• Sharing one capacitor between two ICs
• Tiny 0402 caps far away "because they fit there"

Key takeaways

• The local reservoir job the foundation of this guide; revisit it if any measurement here surprises you.
• Value stacks and why the foundation of this guide; revisit it if any measurement here surprises you.
• Placement geometry the foundation of this guide; revisit it if any measurement here surprises you.

Who this guide is for

Beginners get a single focused topic instead of a whole textbook chapter. It assumes the track’s earlier pages in the PCB design complete guide path. Intermediate readers use it as a reference the table, the worked example and the mistake list answer the questions that come up mid-build. If you teach, the structure (theory, application, example, failure modes) maps cleanly onto a lab session.

What you need before starting

Nothing exotic: the parts or tools named in the guide, a multimeter. The Capacitor Code (3-Digit) / RC Time Constant open in a tab. Place the fastest capacitor closest to each power pin before you begin the guide assumes it and keep the quick-reference table above within sight while you work through the steps.

Quick reference card

Aspect	Where to find it in this guide
Core theory	The local reservoir job
Application steps	How to apply this in your build
Worked numbers	Worked example
Failure modes	Common mistakes to avoid

How this fits the PCB design complete guide track

This guide is one stop in the structured learning path. Start from the PCB design complete guide complete guide for the full map, or continue with layout best practices and assembly defect guide. For the arithmetic, open the Capacitor Code (3-Digit) or RC Time Constant.

Frequently asked questions

Is more capacitance always better? Beyond covering the decades, extra bulk slows regulator response and inrush value stack beats dumping capacitance.

X7R or C0G for decoupling? X7R for the bulk of decoupling duty; C0G reserved where linearity and losses matter (RF, timing).

Is there a calculator for this? Yes the Capacitor Code (3-Digit) and RC Time Constant tools run the formulas from this guide instantly, client-side, with no signup.
