Class AB is the default analog power stage. A push-pull pair, each handling opposite half-cycles, biased slightly on so the handover between them never fully switches off. Efficiency reaches 50-78 % theoretically; the engineering battle is at the crossover.
At a glance: 8 minute guide · part 6 of 10 in the amplifiers complete guide track · includes a worked example and a quick-reference table.
Push-pull basics
The upper device sources current into the load on positive half-cycles; the lower sinks on negative. Each idles at a small quiescent current enough that neither enters hard cutoff during the handover, the trick that separates AB from B and its notorious crossover notch.
| Aspect | Class B | Class AB | Class A |
|---|---|---|---|
| Conduction | 180° each | Slightly >180° | 360° |
| Idle current | ≈ 0 | Small, critical | Maximum |
| Crossover distortion | Severe | Engineered out | None |
| Efficiency (theory) | 78.5 % max | Approaches 78.5 % | ≤ 50 % |
| Thermal care | Bias tracking | Essential | Continuous |
Bias, temperature and the Vbe multiplier
Output device Vbe falls ~2 mV/°C; uncorrected, warm output stages over-bias and thermal-run. A Vbe multiplier transistor bolted to the same heatsink tracks and re-trims bias the classic stable AB output bias servo.
Realistic distortion behaviour
Crossover residue shrinks with optimal quiescent current then returns as gm doubling at over-bias. Factory service manuals specify bias in milliamps for a reason. Measurement across temperature is how the design earns "hi-fi".
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly.
- Set quiescent current to the design value at operating temperature
- Mount the bias sensor on the output heatsink
- Verify stability into reactive loads
- Measure distortion at low output where crossover lives
Worked example
An amplifier measured 0.5 % THD at 1 W with bias 20 % low the crossover notch dominated. Setting the specified 40 mA and letting the multiplier track brought it under 0.02 %. Run the numbers yourself with the Electrical Power Calculator and the result should agree to within rounding.
Practical note from the bench. Servicing wisdom: measure output-stage idle current before touching anything else in an aging amp half of "aging sound" is drifted bias.
Pitfalls that cost real hardware
- Biasing "by ear" instead of measured current
- Mounting the Vbe multiplier away from the output devices
- Substituting output transistors without re-checking bias
Key takeaways
- Push-pull basics the foundation of this guide; revisit it if any measurement here surprises you.
- Bias, temperature and the Vbe multiplier the foundation of this guide. Revisit it if any measurement here surprises you.
- Realistic distortion behaviour the foundation of this guide; revisit it if any measurement here surprises you.
Prerequisites and preparation
Before starting: set quiescent current to the design value at operating temperature and mount the bias sensor on the output heatsink. Keep the Electrical Power Calculator open every number in the worked example is reproducible. Total time including the bench steps: about 6-8 minutes.
Who benefits most
Hobbyists meeting this topic for the first time, students who want the version with real numbers instead of abstract symbols. Returning engineers refreshing a corner of the craft. The mistake list alone justifies the visit every entry in it was learned the expensive way.
Quick reference card
| Aspect | Where to find it in this guide |
|---|---|
| Core theory | Push-pull basics |
| Application steps | How to apply this in your build |
| Worked numbers | Worked example |
| Failure modes | Pitfalls that cost real hardware |
How this fits the amplifiers complete guide track
This guide is one stop in the structured learning path. Start from the amplifiers complete guide complete guide for the full map, or continue with Class A comparison and Class D technology. For the arithmetic, open the Electrical Power Calculator.
Frequently asked questions
Why does my Class AB amp distort at low volume? Crossover distortion is a fixed residue largest relative to small signals. Correct bias is the cure.
Can I raise bias toward Class A? Somewhere between lies "Class AAB" until heatsink physics vetoes. Thermal maths decides.
Is there a calculator for this? Yes the Electrical Power Calculator tool runs the formulas from this guide instantly, client-side, with no signup.
What to read after this
- The complete amplifiers & audio guide: Amplifiers & Audio complete guide
- Read next: inverting op-amp: gain, virtual ground and design
- Also in this track: non-inverting op-amp: high-impedance gain stage
- Continue with: the op-amp voltage follower: small circuit, big leverage
- Calculate as you go: op-amp gain calculator · power dissipation tool · gain to dB converter
- From here, the natural continuation is the next guide in the track index. It assumes exactly the vocabulary this page built and adds the next layer of practice.
Field notes
Component substitution is a legitimate experiment as long as it is deliberate. Swap one part, predict the effect, measure, and record. That single habit converts a parts bin into a teaching lab and makes every future guide in this track faster to absorb.
The fastest way to internalise this topic is to change one variable deliberately and predict the result before measuring. Wrong predictions are the curriculum, they show exactly which mental model needs revisiting, and the bench grades honestly.
Formulas and checks from this guide
Verification checklist for this track: measure bias at idle before signal testing, check heatsink temperature under load. Confirm gain across frequency rather than at 1 kHz alone. Amplifiers forgive nothing at their edges.
Bookmark this page against your next build in the track. The checklist above is the same one used across 19 guides in this series.
Field lessons worth keeping
Thermal drift in bias. Check the bias tracker is bolted to the heatsink and re-set per the service values.
Across the emitter resistors at idle, no signal. Compare each output device.
The habit that makes this stick
A note on thermal reality, which ends most arguments in this track: dissipation is set at idle, verified under load, and never forgiven by a bigger heatsink alone.
Working through Push-pull basicsand Bias, temperature and the Vbe multiplier with that habit in mind takes minutes, and it is the difference between reading about this topic and owning it.
Extended Application Notes
This section expands the practical application of class ab push-pull: the workhorse output stage beyond the worked example, into the situations builders actually meet. Component substitution: when the exact specified part is unavailable, the substitution logic follows the governing parameter of this design, not the nominal value, and the verification step after any substitution is to re-measure the one quantity this guide identified as critical. Batch variation: components vary, and the design margins recommended in the sections above absorb that variation; if a second build behaves differently, the difference itself is diagnostic and points to the tolerance that dominated. Environmental limits: temperature, supply variation and ageing each push a real circuit away from its bench behaviour, and the recommended practice is to test the extremes deliberately rather than discover them in the field. These notes exist because the bench taught them, repeatedly, and each one was once a real troubleshooting session that ended in understanding.
Failure Analysis in Depth
The mistakes section above lists the traps; this section explains why each trap exists and how to recognize it early. Biasing "by ear" instead of measured current Mounting the Vbe multiplier away from the output devices Substituting output transistors without re-checking bias. Each of these failures has a signature that appears in measurement before it appears in smoke: a reading that drifts, a waveform that differs from the prediction, a temperature that climbs faster than the calculation. The discipline this guide teaches is to measure at the first sign, not at the last, and the sections above give the specific instrument and setting for each check. Failure analysis is not pessimism; it is the fastest curriculum in electronics, because a fault understood once is a fault prevented forever.
Pre-Build Checklist
Before powering any build of this design, run the list: every component value verified against the specification above, the critical measurement points identified and accessible, the instrument modes and ranges chosen in advance, the expected values written down beside the bench, and the power source current-limited for first application. The checklist takes two minutes and replaces the most expensive class of beginner error, which is not ignorance but confidence outrunning verification. Builders who adopt the checklist across the guides in this track report first-apply success rates that feel like cheating, but it is not cheating, it is engineering.
What Comes Next
Having worked through this guide, the natural next steps are the adjacent guides in the track index above, each of which assumes exactly the vocabulary this page built. The calculators linked in the tools section verify every number in seconds, and the complete guide at the head of this track maps the entire curriculum. Read once, build once, measure always: that is the method this site teaches and the method every section above followed before publication.
Theory in Practice, Extended
The theory section of class ab push-pull: the workhorse output stage deserves one more pass with the bench in mind, because knowing a relationship and applying it under constraint are different skills. In application, the relationship is never isolated: it interacts with tolerances, with temperature, with the behaviour of adjacent stages, and with the measurement itself. The extended practice is to take the governing formula from the sections above and stress it, deliberately. Push the input to the edge of its specified range and watch the output follow the prediction, then push past it and watch the prediction break, because the edge of the specification is exactly where the formula stops being the whole story. That boundary, found on the bench rather than in the datasheet, is the real knowledge this guide offers beyond the mathematics.
Component Sourcing and Substitution Notes
Real builds meet real supply chains, and this section addresses the practical reality. The specified components in this guide were chosen for the reasons stated in the design sections, but equivalent parts from reputable manufacturers almost always serve, provided the governing parameters match, not merely the nominal ones. The substitution checklist: match the parameter this guide identified as critical, verify the package and pinout against the physical part before layout, check the datasheet revision for silent changes, and re-run the verification measurement after installation. Avoid unbranded surplus and marketplace components for anything this guide treats as safety-relevant; the failure mode of a counterfeit is not degradation, it is unpredictability, and unpredictability defeats every other design decision in the chain.
Instrumentation for This Design
Every measurement recommended in this guide maps to a specific instrument configuration, and this section consolidates them. Voltage checks: DC range selected before probing, leads verified against a known source, meter burden considered when the node is high impedance. Current checks: circuit broken at the defined point, meter inserted with the correct range and fuse status confirmed first. Waveform checks: probe compensated against the reference before any amplitude claim, ground lead kept short, bandwidth sufficient for the edge rather than the repetition rate. The instrumentation discipline matters more than the instrument class, and a modest instrument used correctly outperforms an expensive one used casually, a claim this site demonstrates throughout its measurement guides.
Documentation Template for This Build
Close the loop the way professional builds do: record the design values from this guide, the as-built values including every substitution, the measured results beside the predicted ones, and the deviation notes that explain every gap. The template is short, a single page, and it converts a successful build into a reference that survives component changes, firmware updates and the passage of months. Every guide on this site was built and documented exactly this way before publication, and the discipline is offered here as part of the curriculum rather than an afterthought. A build that is documented is twice built, once in copper and once in confidence.
