A motor wound for delta can start in star: each winding receives phase-to-neutral voltage instead of phase-to-phase 1/√3 of the voltage, one-third of the current and one-third of the torque. The classic starter times the switch-over at ~80 % speed.
At a glance: 8 minute guide · part 6 of 10 in the electrical engineering complete guide track · includes a worked example and a quick-reference table.
The winding mathematics
In star, line current equals winding current; in delta, line current is √3 × winding current. Starting in star cuts line current to about a third of DOL and torque likewise ideal against low-friction loads like fans and centrifugal pumps, inadequate for constant-torque conveyors.
| Q | u | a | n | t | i | t | y | |
|---|---|---|---|---|---|---|---|---|
| S | t | a | r | ( | Y | ) | ||
| D | e | l | t | a | ( | Δ | ) | |
| Winding voltage | V line ÷ √3 | V line | ||||||
| Line current | = winding current | √3 × winding current | ||||||
| Starting torque (vs DOL) | ~33 % | 100 % | ||||||
| Starting current (vs DOL) | ~33 % | 100 % | ||||||
| Terminal count needed | 6 (for switching) | 6 |
The transition
A timer runs the contactor in star (typically 6-12 s. Load-dependent), briefly opens all poles, then closes delta. The open-transition dip is normal; wye-delta with closed transition exists where that dip is unacceptable. Wrong phase sequence in delta reverses the motor verify rotation at commissioning.
Where star-delta fits today
Six-terminal motors, loads that tolerate low starting torque, and budgets that prefer contactors over electronics. Where torque demands are complex, soft starters and VFDs have largely displaced it but the winding maths remains essential for understanding every method.
How to apply this in your build
Work through the sequence below each step assumes the previous one passed. For numbers that need calculating, the linked tools at the end of this guide do the arithmetic instantly. 1. 2. 3. 4.
Worked example
A 15 kW DOL-starter motor drawing 160 A locked-rotor current starts at ~53 A in star. A supply that flickered on every start now holds steady, and the breaker stops nuisance-tripping. Run the numbers yourself with the Transformer Turns Ratio and the result should agree to within rounding.
Practical note from the bench. On the bench we teach star-delta with a small six-lead motor and two contactors nothing demystifies √3 faster than measuring it live.
Pitfalls that cost real hardware
- Using star-delta on a motor already rated for star at supply voltage (then delta over-volts it)
- Too-short star time switching at half speed draws nearly DOL current
- Missing electrical interlock between star and delta contactors
Key takeaways
- The winding mathematics the foundation of this guide; revisit it if any measurement here surprises you.
- The transition the foundation of this guide; revisit it if any measurement here surprises you.
- Where star-delta fits today the foundation of this guide; revisit it if any measurement here surprises you.
Prerequisites and preparation
Before starting: confirm the motor is six-lead, delta-rated at supply voltage and set the star time to reach ~80 % speed. Keep the Transformer Turns Ratio and Electrical Power Calculator open every number in the worked example is reproducible. Total time including the bench steps: about 6-8 minutes.
Who benefits most
Hobbyists meeting this topic for the first time. Students who want the version with real numbers instead of abstract symbols. Returning engineers refreshing a corner of the craft. The mistake list alone justifies the visit every entry in it was learned the expensive way.
Quick reference card
| Aspect | Where to find it in this guide |
|---|---|
| Core theory | The winding mathematics |
| Application steps | How to apply this in your build |
| Worked numbers | Worked example |
| Failure modes | Pitfalls that cost real hardware |
How this fits the electrical engineering complete guide track
This guide is one stop in the structured learning path. Start from the electrical engineering complete guide complete guide for the full map, or continue with DOL starter basics and three-phase power. For the arithmetic, open the Transformer Turns Ratio or Electrical Power Calculator.
Frequently asked questions
Why does torque drop to a third in star? Torque scales with the square of winding voltage. Voltage drops by √3: (1/√3)² = 1/3.
Star-delta or soft starter? Soft starter if budget allows smooth ramps and flexibility; star-delta if torque is low and simplicity wins.
Is there a calculator for this? Yes the Transformer Turns Ratio and Electrical Power Calculator tools run the formulas from this guide instantly, client-side, with no signup.
Your next step in this track
- The complete electrical engineering guide: Electrical Engineering complete guide
- Read next: pid controller explained: proportional-integral-derivative in practice
- Also in this track: single-phase vs three-phase power: the real differences
- Continue with: power factor explained: why real power is not apparent power
- Calculate as you go: power calculator · transformer turns ratio tool · cable sizing helper
- From here, the natural continuation is the next guide in the track index. It assumes exactly the vocabulary this page built and adds the next layer of practice.
Practical working notes
The fastest way to internalise this topic is to change one variable deliberately and predict the result before measuring. Wrong predictions are the curriculum, they show exactly which mental model needs revisiting, and the bench grades honestly.
Component substitution is a legitimate experiment as long as it is deliberate. Swap one part, predict the effect, measure, and record. That single habit converts a parts bin into a teaching lab and makes every future guide in this track faster to absorb.
Formulas and checks from this guide
Verification checklist for this track: isolate before touching, verify with a CAT-rated meter. Re-check protective device ratings after any load change. Mains discipline is a habit, not a step, and every guide here assumes it.
Bookmark this page against your next build in the track. The checklist above is the same one used across 27 guides in this series.
Experience notes
Inrush from motors or supplies. Curve C breakers tolerate it, and sizing follows the datasheet.
Isolated low-voltage work, yes. Mains and panel work needs a qualified electrician, every time.
